Acoustic Pipe Lagging Insulation- Thermotec Nuwrap5

Description

Acoustic Pipe Lagging Insulation – Thermotec Nuwrap5

Nuwrap5 acoustic pipe insulation wrap is an effective, easy-to-install solution for quietening noisy pipes in residential and commercial properties. Australian Made & meets BCA requirements.

Acoustic Pipe Insulation Wrap – Silence Noisy Pipes!

Lagging noisy pipes is becoming ever more important in modern day residential and commercial construction. We’re all searching for more privacy and quieter living spaces.

Thermotec NuWrap 5 acoustic pipe insulation wrap is an effective, easy-to-install solution to help silence noisy pipes forever. Specifically designed to meet Australia BCA compliance and AS/NZS1530.3.

We especially recommend using Nuwrap5 pipe acoustic lagging to wrap around noisy waste water or sewer pipes. To explore other ways to manage noise transfer in buildings, you can check out our guide on Acoustic Insulation Types.

Other Acoustic Applications

Nuwrap5 acoustic pipe insulation wrap can also help to reduce sound in the following applications:

• Air conditioning ductwork
• Ventilation fan housings
• Machinery housings – pool pumps, generator enclosures
• Noise transfer between rooms

Composition of Nuwrap5 Acoustic Pipe Lagging

Nuwrap5 has 3 layers laminated together to create a flexible, easy to cut & install acoustic pipe insulation wrap.

Nuwrap5 uses a heavy-duty flexible sound-blocking layer as the main acoustic barrier. On 1 side of this barrier is a special foam decoupling layer that breaks the vibration path between the pipe and the sound barrier. Finally, we apply a facing of reinforced foil to the other side for fire protection using quality tapes such as Kingspan Aluminium Foil Tape.

The combination creates a high performance, flexible, easy to install pipe lagging that provides excellent sound reduction from pipework.

Need High Quality, Fire Safe Pipe Lagging That Complies with Australian Standards?

Building Code of Australia compliance is essential for any product you use in your home. Knowing that, Thermotec Australia proudly makes Nuwrap5 pipe lagging right here in Oz, using only the best quality ingredients.

NuWrap5 acoustic pipe insulation wrap meets BCA requirements for all States and Territories in Australia. Plus, if you install it to the manufacturers’ recommendations, it needs no further regulatory body approval or certification.

To ensure the optimum fire resistance as required by Australian Standard AS1530.3, Nuwrap5 comes with a reinforced foil facing. This facing provides a 4 zero’s fire rating which is the highest possible for the test.

Acoustic Performance of Nuwrap 5

Acoustic performance of a pipe lagging insulation is of utmost importance. So when purchasing lagging products, it makes sense to buy a product that Australian Labs have tested for Australia.

Recent acoustic testing confirms that NuWrap 5™ continues to be compliant to the NCC requirements for habitable areas. The provisions of F7F1 of the National Construction Code 2022 Volume 1 – Building Code of Australia 1st May 2023.

Just one wrap around the pipe using Nuwrap5 combined with a standard 10mm plasterboard ceiling exceeds this requirement. It requires no further fiber batt in the ceiling. For other ceiling soundproofing options, you can view our Polyester Sound Control Batts or Bradford Soundscreen Insulation Batts.

Nuwrap-5 Acoustic Pipe Lagging Product Dimensions

Available in 1.35mx3m Roll = 4.05m2 as standard. Half rolls may also be available in some locations. (5 meter Roll length may also be available upon request, but requires a minimum of 30 full rolls purchase.)

Nuwrap5 acoustic pipe insulation wrap typically suits pipe diameters from 40mm to 225mm and suits most PVC fittings.

Pre cut flat packs may be available upon request.

Environmental Credentials for Nuwrap5

Nuwrap-5 acoustic pipe insulation has low VOC and EDP-EM19 credentials. Zero ozone depleting substances in the materials composition or employed during the manufacturing process. Nuwrap5 is also Green Star compliant.

Nuwrap5 Acoustic Pipe Lagging Insulation Delivery Options

We offer pick up option for Nuwrap5 from our warehouses in Brisbane, Gold Coast, Sydney, Melbourne or Adelaide.

Delivery is possible for most locations in Australia and is usually auto calculated at checkout. If no standard freight option is available please use our Freight Quote Request Form.

Soundproofing Products Australia online store sells a wide range of soundproofing and acoustic solutions. You can explore our complete Shop, or browse other noise control categories like our Acoustic Barriers and Polyester Insulation.

If you have any questions or require a particular delivery quotation, don’t hesitate to Contact Us! You can also get an obligation free quote. For additional information about the Warranty & Shipping Information and Delivery & Returns, please check our policy pages.
